IRFP4228PBF

Technical Details

• Series:HEXFET®
• Package:Bulk
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):150 V
• Current - Continuous Drain (Id) @ 25°C:78A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:15.5mOhm @ 33A, 10V
• Vgs(th) (Max) @ Id:5V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:107 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:4530 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):310W (Tc)
• Operating Temperature:-40°C ~ 175°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-247AC
• Package / Case:TO-247-3
