NTF3055L175T3G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 60V 2A SOT223
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NTF3055L175T3G Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):60 V
- Current - Continuous Drain (Id) @ 25°C:2A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):5V
- Rds On (Max) @ Id, Vgs:175mOhm @ 1A, 5V
- Vgs(th) (Max) @ Id:2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:10 nC @ 5 V
- Vgs (Max):±15V
- Input Capacitance (Ciss) (Max) @ Vds:270 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):1.3W (Ta)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:SOT-223 (TO-261)
- Package / Case:TO-261-4, TO-261AA
