IXFT21N50Q
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 500V 21A TO268
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXFT21N50Q Datasheet
-
ECAD Model
- Share
In Stock: 164
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:HiPerFET™
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):500 V
- Current - Continuous Drain (Id) @ 25°C:21A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:250mOhm @ 10.5A, 10V
- Vgs(th) (Max) @ Id:4.5V @ 4mA
- Gate Charge (Qg) (Max) @ Vgs:84 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:3000 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):280W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:TO-268
- Package / Case:TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
