SI1012X-T1-E3
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 20V 500MA SC89-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet SI1012X-T1-E3 Datasheet
-
ECAD Model
- Share
In Stock: 123
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:TrenchFET®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:500mA (Ta)
- Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
- Rds On (Max) @ Id, Vgs:700mOhm @ 600mA, 4.5V
- Vgs(th) (Max) @ Id:900mV @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:0.75 nC @ 4.5 V
- Vgs (Max):±6V
- Input Capacitance (Ciss) (Max) @ Vds:-
- FET Feature:-
- Power Dissipation (Max):250mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:SC-89-3
- Package / Case:SC-89, SOT-490
