SI1471DH-T1-E3
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 30V 2.7A SC70-6
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet SI1471DH-T1-E3 Datasheet
-
ECAD Model
- Share
In Stock: 193
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:TrenchFET®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:2.7A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):2.5V, 10V
- Rds On (Max) @ Id, Vgs:100mOhm @ 2A, 10V
- Vgs(th) (Max) @ Id:1.6V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:9.8 nC @ 4.5 V
- Vgs (Max):±12V
- Input Capacitance (Ciss) (Max) @ Vds:445 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):1.5W (Ta), 2.78W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:SC-70-6 (SOT-363)
- Package / Case:6-TSSOP, SC-88, SOT-363
