APTM50SKM38TG
Microsemi
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 500V 90A SP4
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet APTM50SKM38TG Datasheet
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):500 V
- Current - Continuous Drain (Id) @ 25°C:90A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:45mOhm @ 45A, 10V
- Vgs(th) (Max) @ Id:5V @ 5mA
- Gate Charge (Qg) (Max) @ Vgs:246 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:11200 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):694W (Tc)
- Operating Temperature:-40°C ~ 150°C (TJ)
- Mounting Type:Chassis Mount
- Supplier Device Package:SP4
- Package / Case:SP4
