DMN5L06T-7

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):50 V
• Current - Continuous Drain (Id) @ 25°C:280mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):1.8V, 2.7V
• Rds On (Max) @ Id, Vgs:3Ohm @ 200mA, 2.7V
• Vgs(th) (Max) @ Id:1.2V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:-
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:50 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):150mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:SOT-523
• Package / Case:SOT-523
