NILMS4501NR2G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 24V 9.5A 4PLLP
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NILMS4501NR2G Datasheet
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):24 V
- Current - Continuous Drain (Id) @ 25°C:9.5A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:13mOhm @ 6A, 10V
- Vgs(th) (Max) @ Id:2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:25 nC @ 10 V
- Vgs (Max):±10V
- Input Capacitance (Ciss) (Max) @ Vds:1500 pF @ 6 V
- FET Feature:Current Sensing
- Power Dissipation (Max):1.4W (Ta)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:4-PLLP
- Package / Case:4-PowerDFN
