MTD6N15T4GV
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 150V 6A DPAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet MTD6N15T4GV Datasheet
-
ECAD Model
- Share
In Stock: 100
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):150 V
- Current - Continuous Drain (Id) @ 25°C:6A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:300mOhm @ 3A, 10V
- Vgs(th) (Max) @ Id:4.5V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:30 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1200 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):1.25W (Ta), 20W (Tc)
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:DPAK
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
