SI8451DB-T2-E1
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 10.8A 6MICROFOOT
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet SI8451DB-T2-E1 Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:TrenchFET®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:10.8A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):1.5V, 4.5V
- Rds On (Max) @ Id, Vgs:80mOhm @ 1A, 4.5V
- Vgs(th) (Max) @ Id:1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:24 nC @ 8 V
- Vgs (Max):±8V
- Input Capacitance (Ciss) (Max) @ Vds:750 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):2.77W (Ta), 13W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:6-Micro Foot™ (1.5x1)
- Package / Case:6-UFBGA
