SUP85N02-03-E3
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 20V 85A TO220AB
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet SUP85N02-03-E3 Datasheet
-
ECAD Model
- Share
In Stock: 172
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:TrenchFET®
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:85A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
- Rds On (Max) @ Id, Vgs:3mOhm @ 30A, 4.5V
- Vgs(th) (Max) @ Id:450mV @ 2mA (Min)
- Gate Charge (Qg) (Max) @ Vgs:200 nC @ 4.5 V
- Vgs (Max):±8V
- Input Capacitance (Ciss) (Max) @ Vds:21250 pF @ 20 V
- FET Feature:-
- Power Dissipation (Max):250W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-220AB
- Package / Case:TO-220-3
