DMG3413L-7
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 3A SOT23
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet DMG3413L-7 Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
- 1$0.13613
- 3,000$0.13613
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:3A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
- Rds On (Max) @ Id, Vgs:95mOhm @ 3A, 4.5V
- Vgs(th) (Max) @ Id:1.3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:9 nC @ 4.5 V
- Vgs (Max):±8V
- Input Capacitance (Ciss) (Max) @ Vds:857 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):700mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:SOT-23
- Package / Case:TO-236-3, SC-59, SOT-23-3
