1N5817-B
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 20V 1A DO41
- CategoryDiodes - Rectifiers - Single
- Datasheet 1N5817-B Datasheet
-
ECAD Model
- Share
In Stock: 533
Can ship immediately
Pricing:
- 1$0.33
- 10$0.246
- 100$0.1419
- 500$0.096
- 1,000$0.075
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Discontinued at Digi-Key
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):20 V
- Current - Average Rectified (Io):1A
- Voltage - Forward (Vf) (Max) @ If:750 mV @ 3 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:1 mA @ 20 V
- Capacitance @ Vr, F:110pF @ 4V, 1MHz
- Mounting Type:Through Hole
- Package / Case:DO-204AL, DO-41, Axial
- Supplier Device Package:DO-41
- Operating Temperature - Junction:-65°C ~ 125°C
