S1AFM-M3/6A
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GEN PURP 1KV 1A DO221AC
- CategoryDiodes - Rectifiers - Single
- Datasheet S1AFM-M3/6A Datasheet
-
ECAD Model
- Share
In Stock: 14,199
Can ship immediately
Pricing:
- 1$0.46
- 3,500$0.10791
- 7,000$0.10259
- 10,500$0.09462
- 24,500$0.0893
- 87,500$0.08664
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):1000 V
- Current - Average Rectified (Io):1A
- Voltage - Forward (Vf) (Max) @ If:1.1 V @ 1 A
- Speed:Standard Recovery >500ns, > 200mA (Io)
- Reverse Recovery Time (trr):1.47 µs
- Current - Reverse Leakage @ Vr:5 µA @ 1000 V
- Capacitance @ Vr, F:7.9pF @ 4V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:DO-221AC, SMA Flat Leads
- Supplier Device Package:DO-221AC (SlimSMA)
- Operating Temperature - Junction:-55°C ~ 150°C
