MBR760-E3/45
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 60V 7.5A TO220AC
- CategoryDiodes - Rectifiers - Single
- Datasheet MBR760-E3/45 Datasheet
-
ECAD Model
- Share
In Stock: 146
Can ship immediately
Pricing:
- 1$0.95
- 50$0.79449
- 100$0.65829
- 500$0.53194
- 1,000$0.43651
- 2,500$0.40073
- 5,000$0.38881
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):60 V
- Current - Average Rectified (Io):7.5A
- Voltage - Forward (Vf) (Max) @ If:750 mV @ 7.5 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:500 µA @ 60 V
- Capacitance @ Vr, F:-
- Mounting Type:Through Hole
- Package / Case:TO-220-2
- Supplier Device Package:TO-220AC
- Operating Temperature - Junction:-65°C ~ 175°C
