1C5822.T
SMC Diode Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 40V 3A DIE
- CategoryDiodes - Rectifiers - Single
- Datasheet 1C5822.T Datasheet
-
ECAD Model
- Share
In Stock: 268
Can ship immediately
Pricing:
- 1$0.6325
- 20$0.6325
- 40$0.57112
- 100$0.49971
- 500$0.38755
- 1,000$0.30595
- 2,000$0.28555
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):40 V
- Current - Average Rectified (Io):3A
- Voltage - Forward (Vf) (Max) @ If:700 mV @ 9.4 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:1.5 mA @ 40 V
- Capacitance @ Vr, F:265pF @ 5V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:Die
- Supplier Device Package:Die
- Operating Temperature - Junction:-55°C ~ 125°C
