SD125SCU100A.T
SMC Diode Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPIV 100V IO 15A CHIP SIZE 125MIL
- CategoryDiodes - Rectifiers - Single
- Datasheet SD125SCU100A.T Datasheet
-
ECAD Model
- Share
In Stock: 146
Can ship immediately
Pricing:
- 1$1.4058
- 20$1.4058
- 40$1.26988
- 100$1.11116
- 500$0.86171
- 1,000$0.6803
- 2,000$0.63494
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):100 V
- Current - Average Rectified (Io):15A
- Voltage - Forward (Vf) (Max) @ If:840 mV @ 15 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:350 µA @ 100 V
- Capacitance @ Vr, F:600pF @ 5V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:Die
- Supplier Device Package:Die
- Operating Temperature - Junction:-55°C ~ 200°C
