STTH506B

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):600 V
• Current - Average Rectified (Io):5A
• Voltage - Forward (Vf) (Max) @ If:1.85 V @ 5 A
• Speed:Fast Recovery =< 500ns, > 200mA (Io)

• Reverse Recovery Time (trr):50 ns
• Current - Reverse Leakage @ Vr:5 µA @ 600 V
• Capacitance @ Vr, F:-
• Mounting Type:Surface Mount
• Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
• Supplier Device Package:DPAK
• Operating Temperature - Junction:175°C (Max)
