1828265
Phoenix Contact
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 4POS STR 7.62MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$10.4
- 10$10.11973
- 50$9.45729
- 100$8.70057
- 250$8.03865
- 500$7.66033
- 1,000$7.18752
Quote It
Technical Details
- Series:COMBICON PC
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:4
- Positions Per Level:4
- Number of Levels:1
- Pitch:0.300" (7.62mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screw - Rising Cage Clamp
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:20A
- Voltage - IEC:1 kV
- Current - UL:5 A
- Voltage - UL:600 V
- Wire Gauge or Range - AWG:10-30 AWG
- Wire Gauge or Range - mm²:0.2-4mm²
- Color:Green
- Operating Temperature:-
- Contact Mating Finish:Tin
- Features:Mating Flange
