ESDLIN1524BJ-HQ
STMicroelectronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 50V 40V SOD323
- CategoryTVS - Diodes
- Datasheet ESDLIN1524BJ-HQ Datasheet
-
ECAD Model
- Share
In Stock: 146
Can ship immediately
Pricing:
- 1$0.1155
- 10,000$0.11303
Quote It
Technical Details
- Series:Automotive, AEC-Q101, ESDL, TRANSIL™
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:-
- Bidirectional Channels:1
- Voltage - Reverse Standoff (Typ):50V
- Voltage - Breakdown (Min):25.4V
- Voltage - Clamping (Max) @ Ipp:40V
- Current - Peak Pulse (10/1000µs):50A
- Power - Peak Pulse:160W
- Power Line Protection:No
- Applications:Automotive
- Capacitance @ Frequency:16pF @ 1MHz
- Operating Temperature:-40°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:SC-76, SOD-323
- Supplier Device Package:SOD-323
