SRP0312-4R7K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 1.9A 210 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 4,390
Can ship immediately
Pricing:
- 1$0.94
Quote It
Technical Details
- Series:SRP0312
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Metal
- Inductance:4.7 µH
- Tolerance:±10%
- Current Rating (Amps):1.9 A
- Current - Saturation (Isat):2.5A
- Shielding:Shielded
- DC Resistance (DCR):210mOhm Max
- Q @ Freq:22 @ 7.96MHz
- Frequency - Self Resonant:29MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.134" L x 0.122" W (3.40mm x 3.10mm)
- Height - Seated (Max):0.047" (1.20mm)
