SRR0735A-100M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 2.1A 72 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR0735A-100M Datasheet
-
ECAD Model
- Share
In Stock: 2,644
Can ship immediately
Pricing:
- 1$1.02
- 3,000$0.43904
Quote It
Technical Details
- Series:SRR0735A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):2.1 A
- Current - Saturation (Isat):1.85A
- Shielding:Shielded
- DC Resistance (DCR):72mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.287" L x 0.287" W (7.30mm x 7.30mm)
- Height - Seated (Max):0.146" (3.70mm)
