CDRH50D28BT150NP-2R2NC
Sumida Corporation- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 3.2A 26MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 2,144
Can ship immediately
Pricing:
- 1$0.94
Quote It
Technical Details
- Series:CDRH50D28B/T150
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±30%
- Current Rating (Amps):3.2 A
- Current - Saturation (Isat):3.5A
- Shielding:Shielded
- DC Resistance (DCR):26mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.209" L x 0.197" W (5.30mm x 5.00mm)
- Height - Seated (Max):0.118" (3.00mm)
