SRP0415-3R3K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 3.2A 82.5 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 3,451
Can ship immediately
Pricing:
- 1$0.98
Quote It
Technical Details
- Series:SRP0415
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Metal
- Inductance:3.3 µH
- Tolerance:±10%
- Current Rating (Amps):3.2 A
- Current - Saturation (Isat):4.6A
- Shielding:Shielded
- DC Resistance (DCR):82.5mOhm Max
- Q @ Freq:40 @ 7.96MHz
- Frequency - Self Resonant:33MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.173" L x 0.161" W (4.40mm x 4.10mm)
- Height - Seated (Max):0.059" (1.50mm)
