VCHA042A-3R3MS6
Delta Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 4.6A 36.8 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 2,107
Can ship immediately
Pricing:
- 1$1.27
- 2,000$0.58
Quote It
Technical Details
- Series:VCHA042A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Metal
- Inductance:3.3 µH
- Tolerance:±20%
- Current Rating (Amps):4.6 A
- Current - Saturation (Isat):3.4A
- Shielding:Unshielded
- DC Resistance (DCR):36.8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 165°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.165" L x 0.157" W (4.20mm x 4.00mm)
- Height - Seated (Max):0.083" (2.10mm)
