B82559B3222A027
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 46.5A 0.68 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 340
Can ship immediately
Pricing:
- 1$8.09
Quote It
Technical Details
- Series:ERU27 - Flat Wire Inductor
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±10%
- Current Rating (Amps):46.5 A
- Current - Saturation (Isat):68A
- Shielding:Shielded
- DC Resistance (DCR):0.68mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:1.094" L x 1.016" W (27.80mm x 25.80mm)
- Height - Seated (Max):0.545" (13.85mm)
