LQW03AW5N4J00D

Technical Details

• Series:LQW03
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Non-Magnetic
• Inductance:5.4 nH
• Tolerance:±5%
• Current Rating (Amps):420 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):210mOhm Max

• Q @ Freq:46 @ 900MHz
• Frequency - Self Resonant:8.5GHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:100 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.021" L x 0.016" W (0.53mm x 0.40mm)
• Height - Seated (Max):0.018" (0.45mm)
