74404041101
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 430MA 1.697 OHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 2,443
Can ship immediately
Pricing:
- 1$1.12
- 4,500$0.594
Quote It
Technical Details
- Series:WE-LQS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:100 µH
- Tolerance:±20%
- Current Rating (Amps):430 mA
- Current - Saturation (Isat):350mA
- Shielding:Semi-Shielded
- DC Resistance (DCR):1.697Ohm
- Q @ Freq:-
- Frequency - Self Resonant:10MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.157" L x 0.157" W (4.00mm x 4.00mm)
- Height - Seated (Max):0.047" (1.20mm)
