SRU8045A-4R7Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 4.6A 27.5MOHM SM
- CategoryFixed Inductors
- Datasheet SRU8045A-4R7Y Datasheet
-
ECAD Model
- Share
In Stock: 2,153
Can ship immediately
Pricing:
- 1$1.19
- 1,000$0.4216
- 3,000$0.4123
Quote It
Technical Details
- Series:SRU8045A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:4.7 µH
- Tolerance:±30%
- Current Rating (Amps):4.6 A
- Current - Saturation (Isat):4.4A
- Shielding:Shielded
- DC Resistance (DCR):27.5mOhm Max
- Q @ Freq:10 @ 7.96MHz
- Frequency - Self Resonant:30MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:4-SMD
- Supplier Device Package:-
- Size / Dimension:0.315" L x 0.315" W (8.00mm x 8.00mm)
- Height - Seated (Max):0.189" (4.80mm)
