SRR1240-120M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 12UH 3.8A 38 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR1240-120M Datasheet
-
ECAD Model
- Share
In Stock: 1,725
Can ship immediately
Pricing:
- 1$1.19
- 800$0.44795
- 1,600$0.4216
- 4,000$0.4123
Quote It
Technical Details
- Series:SRR1240
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:12 µH
- Tolerance:±20%
- Current Rating (Amps):3.8 A
- Current - Saturation (Isat):3.6A
- Shielding:Shielded
- DC Resistance (DCR):38mOhm Max
- Q @ Freq:16 @ 2.52MHz
- Frequency - Self Resonant:25MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.177" (4.50mm)
