EST1040T221MDGA
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 410MA 636 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 1,492
Can ship immediately
Pricing:
- 1$1.31
Quote It
Technical Details
- Series:ES, T Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±20%
- Current Rating (Amps):410 mA
- Current - Saturation (Isat):770mA
- Shielding:Shielded
- DC Resistance (DCR):636mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:4.2MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.398" L x 0.394" W (10.10mm x 10.00mm)
- Height - Seated (Max):0.169" (4.30mm)
