SRP4020FA-2R2M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 8A 23.5 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRP4020FA-2R2M Datasheet
-
ECAD Model
- Share
In Stock: 2,354
Can ship immediately
Pricing:
- 1$1.5
Quote It
Technical Details
- Series:SRP4020FA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron Powder
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):8 A
- Current - Saturation (Isat):3.8A
- Shielding:Shielded
- DC Resistance (DCR):23.5mOhm Max
- Q @ Freq:15 @ 100kHz
- Frequency - Self Resonant:38MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 155°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.161" L x 0.161" W (4.10mm x 4.10mm)
- Height - Seated (Max):0.083" (2.10mm)
