SRR1280A-221K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 1.6A 400MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR1280A-221K Datasheet
-
ECAD Model
- Share
In Stock: 1,602
Can ship immediately
Pricing:
- 1$1.52
- 400$0.7027
- 800$0.56885
- 1,200$0.53539
- 2,800$0.52358
Quote It
Technical Details
- Series:SRR1280A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±10%
- Current Rating (Amps):1.6 A
- Current - Saturation (Isat):1.7A
- Shielding:Shielded
- DC Resistance (DCR):400mOhm Max
- Q @ Freq:24 @ 796kHz
- Frequency - Self Resonant:3.4MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:1280
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.315" (8.00mm)
