110001150
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.41UH 18.5A 1.1 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 917
Can ship immediately
Pricing:
- 1$4.23
- 400$1.90003
Quote It
Technical Details
- Series:WE-SDP
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:1.41 µH
- Tolerance:±20%
- Current Rating (Amps):18.5 A
- Current - Saturation (Isat):14A
- Shielding:Unshielded
- DC Resistance (DCR):1.1mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Radial, Horizontal Cylinder (Open)
- Supplier Device Package:-
- Size / Dimension:0.362" Dia x 0.984" L (9.20mm x 25.00mm)
- Height - Seated (Max):-
