B82477P4682M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 6.6A 15 MOHM SMD
- CategoryFixed Inductors
- Datasheet B82477P4682M000 Datasheet
-
ECAD Model
- Share
In Stock: 1,343
Can ship immediately
Pricing:
- 1$2.26
- 350$1.2992
- 700$1.22702
- 1,050$1.11874
- 3,500$1.08266
- 8,750$1.04658
Quote It
Technical Details
- Series:B82477P4
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):6.6 A
- Current - Saturation (Isat):7.3A
- Shielding:Shielded
- DC Resistance (DCR):15mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.335" (8.50mm)
