MPX1D1770L6R8

KEMET
  • Lifecycle status Active
  • RoHS RoHS Compliant
  • DescriptionFIXED IND 6.8UH 19.5A 6.8 MOHM
  • CategoryFixed Inductors
  • ECAD Model
  • Share
In Stock: 307

Can ship immediately

Pricing:
  • 1$6.15

Quote It

Technical Details

  • Series:METCOM MPX
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Type:Wirewound
  • Material - Core:Metal Composite
  • Inductance:6.8 µH
  • Tolerance:±20%
  • Current Rating (Amps):19.5 A
  • Current - Saturation (Isat):26A
  • Shielding:Shielded
  • DC Resistance (DCR):6.8mOhm Max



  • Q @ Freq:-
  • Frequency - Self Resonant:8MHz
  • Ratings:-
  • Operating Temperature:-55°C ~ 155°C
  • Inductance Frequency - Test:100 kHz
  • Features:-
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Supplier Device Package:-
  • Size / Dimension:0.669" L x 0.673" W (17.00mm x 17.10mm)
  • Height - Seated (Max):0.276" (7.00mm)

Related Products


103-680K

FIXED IND 68NH 705MA 195 MOHM

103-680K Datasheet
  • 1: $6.17386
  • 1000: $ 3.71490

SH150S-1.87-53

FIXED IND 53UH 1.87A 130 MOHM

SH150S-1.87-53 Datasheet
  • 1: $6.23000
  • 250: $ 3.12800
  • 500: $2.94400

M27/370-06

FIXED IND 2.7UH 5.03A 14 MOHM

M27/370-06 Datasheet
  • 1: $6.57000
  • 480: $ 2.31200
  • 960: $2.10800

SH50F-0.9-330

FIXED IND 330UH 900MA 740 MOHM

SH50F-0.9-330 Datasheet
  • 1: $6.57000
  • 10: $6.02310
  • 100: $3.94200

LGJ12575TS-331M1R0-H

FIXED IND 330UH 1.1A 340 MOHM

LGJ12575TS-331M1R0-H Datasheet
  • 1: $7.26000
  • 500: $4.50120
  • 1000: $4.21080

LGJ12575TS-2R7N7R0-H

FIXED IND 2.7UH 7A 7.4 MOHM SMD

LGJ12575TS-2R7N7R0-H Datasheet
  • 1: $7.26000
  • 500: $4.50120
  • 1000: $4.21080

LGJ12575TS-471MR80-H

FIXED IND 470UH 800MA 600 MOHM

LGJ12575TS-471MR80-H Datasheet
  • 1: $7.26000
  • 500: $4.50120
  • 1000: $4.21080

LGJ12575TS-1R2N8R2-H

FIXED IND 1.2UH 8.2A 5.1 MOHM

LGJ12575TS-1R2N8R2-H Datasheet
  • 1: $7.26000
  • 500: $4.50120
  • 1000: $4.21080

LGJ12565TS-2R0N6R2-H

FIXED IND 2UH 6.2A 8 MOHM SMD

LGJ12565TS-2R0N6R2-H Datasheet
  • 1: $7.26000
  • 500: $4.09200
  • 1000: $3.82800

LGJ12565TS-471MR70-H
