3613C101K
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 110MA 8 OHM SMD
- CategoryFixed Inductors
- Datasheet 3613C101K Datasheet
-
ECAD Model
- Share
In Stock: 691
Can ship immediately
Pricing:
- 1$0.62
- 500$0.28338
- 1,000$0.2294
- 2,500$0.2159
- 5,000$0.20916
- 12,500$0.20241
- 25,000$0.19566
- 50,000$0.18892
Quote It
Technical Details
- Series:3613C, Sigma Inductors
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:100 µH
- Tolerance:±10%
- Current Rating (Amps):110 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):8Ohm Max
- Q @ Freq:40 @ 796kHz
- Frequency - Self Resonant:8MHz
- Ratings:-
- Operating Temperature:-30°C ~ 100°C
- Inductance Frequency - Test:796 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.134" (3.40mm)
