SDR1006-222KL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2MH 160MA 7.6OHM SMD
- CategoryFixed Inductors
- Datasheet SDR1006-222KL Datasheet
-
ECAD Model
- Share
In Stock: 1,052
Can ship immediately
Pricing:
- 1$0.88
- 800$0.306
- 1,600$0.289
- 4,000$0.272
- 5,600$0.266
Quote It
Technical Details
- Series:SDR1006
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 mH
- Tolerance:±10%
- Current Rating (Amps):160 mA
- Current - Saturation (Isat):360mA
- Shielding:Unshielded
- DC Resistance (DCR):7.6Ohm Max
- Q @ Freq:31 @ 252kHz
- Frequency - Self Resonant:1.5MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.386" L x 0.386" W (9.80mm x 9.80mm)
- Height - Seated (Max):0.228" (5.80mm)
