RLB0812-222JL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2MH 80MA 8 OHM TH
- CategoryFixed Inductors
- Datasheet RLB0812-222JL Datasheet
-
ECAD Model
- Share
In Stock: 723
Can ship immediately
Pricing:
- 1$0.4
- 10$0.35097
- 100$0.24129
- 500$0.20619
- 1,000$0.15794
- 2,500$0.14916
Quote It
Technical Details
- Series:RLB
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 mH
- Tolerance:±5%
- Current Rating (Amps):80 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):8Ohm Max
- Q @ Freq:60 @ 252kHz
- Frequency - Self Resonant:750kHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:252 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.264" Dia (6.70mm)
- Height - Seated (Max):0.433" (11.00mm)
