SDR1005-6R8ML
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 3.4A 30 MOHM SMD
- CategoryFixed Inductors
- Datasheet SDR1005-6R8ML Datasheet
-
ECAD Model
- Share
In Stock: 894
Can ship immediately
Pricing:
- 1$0.84
- 600$0.33915
- 1,200$0.27455
- 3,000$0.2584
- 6,000$0.2527
Quote It
Technical Details
- Series:SDR1005
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):3.4 A
- Current - Saturation (Isat):4.5A
- Shielding:Unshielded
- DC Resistance (DCR):30mOhm Max
- Q @ Freq:56 @ 2MHz
- Frequency - Self Resonant:31MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.500" L x 0.394" W (12.70mm x 10.00mm)
- Height - Seated (Max):0.197" (5.00mm)
