CLF10040T-330M-D
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 33UH 1.7A 96 MOHM SMD
- CategoryFixed Inductors
- Datasheet CLF10040T-330M-D Datasheet
-
ECAD Model
- Share
In Stock: 979
Can ship immediately
Pricing:
- 1$1.82
Quote It
Technical Details
- Series:CLF-D
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:33 µH
- Tolerance:±20%
- Current Rating (Amps):1.7 A
- Current - Saturation (Isat):2.2A
- Shielding:Shielded
- DC Resistance (DCR):96mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.394" L x 0.382" W (10.00mm x 9.70mm)
- Height - Seated (Max):0.161" (4.10mm)
