SBCP-80HY680H
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 68UH 1.7A 160 MOHM TH
- CategoryFixed Inductors
- Datasheet SBCP-80HY680H Datasheet
-
ECAD Model
- Share
In Stock: 781
Can ship immediately
Pricing:
- 1$2.24
- 2,000$1.0695
Quote It
Technical Details
- Series:SBCP
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:68 µH
- Tolerance:±10%
- Current Rating (Amps):1.7 A
- Current - Saturation (Isat):1.8A
- Shielding:Unshielded
- DC Resistance (DCR):160mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-20°C ~ 105°C
- Inductance Frequency - Test:10 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.374" Dia (9.50mm)
- Height - Seated (Max):0.433" (11.00mm)
