MLF2012K560M
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 56UH 4MA 2.8 OHM SMD
- CategoryFixed Inductors
- Datasheet MLF2012K560M Datasheet
-
ECAD Model
- Share
In Stock: 734
Can ship immediately
Pricing:
- 1$0.17
- 2,000$0.0714
- 4,000$0.0612
- 6,000$0.0578
- 10,000$0.0544
- 50,000$0.051
- 100,000$0.0493
Quote It
Technical Details
- Series:MLF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:56 µH
- Tolerance:±20%
- Current Rating (Amps):4 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):2.8Ohm Max
- Q @ Freq:35 @ 2MHz
- Frequency - Self Resonant:10MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:2 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.057" (1.45mm)
