MLZ2012M1R5HTD25
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 700MA 140 MOHM
- CategoryFixed Inductors
- Datasheet MLZ2012M1R5HTD25 Datasheet
-
ECAD Model
- Share
In Stock: 869
Can ship immediately
Pricing:
- 1$0.2
- 2,000$0.08353
Quote It
Technical Details
- Series:MLZ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:1.5 µH
- Tolerance:±20%
- Current Rating (Amps):700 mA
- Current - Saturation (Isat):550mA
- Shielding:Shielded
- DC Resistance (DCR):140mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:2 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.057" (1.45mm)
