LQW2BAS24NJ00L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 24NH 500MA 220 MOHM
- CategoryFixed Inductors
- Datasheet LQW2BAS24NJ00L Datasheet
-
ECAD Model
- Share
In Stock: 790
Can ship immediately
Pricing:
- 1$0.23
- 2,000$0.0966
- 4,000$0.0828
- 6,000$0.0782
- 10,000$0.0736
- 50,000$0.069
- 100,000$0.0667
Quote It
Technical Details
- Series:LQW2
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Air
- Inductance:24 nH
- Tolerance:±5%
- Current Rating (Amps):500 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):220mOhm Max
- Q @ Freq:50 @ 500MHz
- Frequency - Self Resonant:2.4GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:250 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2015 Metric)
- Supplier Device Package:-
- Size / Dimension:0.082" L x 0.060" W (2.09mm x 1.53mm)
- Height - Seated (Max):0.060" (1.52mm)
