LQW2UAS22NG00L

Technical Details

• Series:LQW2
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:-
• Inductance:22 nH
• Tolerance:±2%
• Current Rating (Amps):1 A
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):120mOhm Max

• Q @ Freq:55 @ 350MHz
• Frequency - Self Resonant:2.4GHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:50 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:1008 (2520 Metric)
• Supplier Device Package:1008 (2520 Metric)
• Size / Dimension:0.103" L x 0.096" W (2.62mm x 2.45mm)
• Height - Seated (Max):0.080" (2.03mm)
