ELJ-NCR22JF
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220NH 145MA 1.15 OHM
- CategoryFixed Inductors
- Datasheet ELJ-NCR22JF Datasheet
-
ECAD Model
- Share
In Stock: 715
Can ship immediately
Pricing:
- 1$0.24
Quote It
Technical Details
- Series:NC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Non-Magnetic
- Inductance:220 nH
- Tolerance:±5%
- Current Rating (Amps):145 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1.15Ohm Max
- Q @ Freq:10 @ 25.2MHz
- Frequency - Self Resonant:260MHz
- Ratings:-
- Operating Temperature:-20°C ~ 85°C
- Inductance Frequency - Test:25.2 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.071" (1.80mm)
