0402HM-150EKTS
Delta Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15NH 460MA 160MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 296
Can ship immediately
Pricing:
- 1$0.24
Quote It
Technical Details
- Series:0402HM
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:15 nH
- Tolerance:±10%
- Current Rating (Amps):460 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):160mOhm
- Q @ Freq:30 @ 250MHz
- Frequency - Self Resonant:5GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402
- Size / Dimension:0.045" L x 0.028" W (1.15mm x 0.70mm)
- Height - Seated (Max):0.024" (0.60mm)
