MHQ1005P2N2CT000
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2NH 1A 60 MOHM SMD
- CategoryFixed Inductors
- Datasheet MHQ1005P2N2CT000 Datasheet
-
ECAD Model
- Share
In Stock: 491
Can ship immediately
Pricing:
- 1$0.26
- 10,000$0.08866
- 30,000$0.0858
- 50,000$0.08294
- 100,000$0.08008
Quote It
Technical Details
- Series:MHQ-P
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ceramic, Non-Magnetic
- Inductance:2.2 nH
- Tolerance:±0.2nH
- Current Rating (Amps):1 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):60mOhm Max
- Q @ Freq:23 @ 250MHz
- Frequency - Self Resonant:8GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.039" L x 0.024" W (1.00mm x 0.60mm)
- Height - Seated (Max):0.024" (0.60mm)
