AISM-1812-100K-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 250MA 1.6 OHM SMD
- CategoryFixed Inductors
- Datasheet AISM-1812-100K-T Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
- 1$0.35
- 500$0.188
- 1,000$0.144
- 2,500$0.136
- 5,000$0.128
- 12,500$0.124
- 25,000$0.12
- 50,000$0.116
Quote It
Technical Details
- Series:AISM-1812
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±10%
- Current Rating (Amps):250 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1.6Ohm Max
- Q @ Freq:50 @ 2.52MHz
- Frequency - Self Resonant:20MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.110" (2.80mm)
